Stress check
The stress calculation for a numerical section is as follows:
with
|
σvm |
the VonMises stress, the composed stress |
|
σtot |
the total normal stress |
|
τtot |
the total shear stress |
|
σN |
the normal stress due to the normal force N |
|
σMy |
the normal stress due to the bending moment Myy around y axis |
|
σMz |
the normal stress due to the bending moment Mzz around z axis |
|
τVy |
the shear stress due to shear force Vy in y direction |
|
τVz |
the shear stress due to shear force Vz in z direction |
|
Ax |
the sectional area |
|
Ay |
the shear area in y direction |
|
Az |
the shear area in z direction |
|
Wy |
the elastic section modulus around y axis |
|
Wz |
the elastic section modulus around z axis |
